Flat Wire Kanthal A1. Lighting Vapes

Kanthal A1 AWG28, 1 meter lenght. Genuine Lighting Vapes

Why use Kanthal A1?

Kanthal A1 is commonly used for electric heating elements in large industrial furnaces and is often found in glass, ceramics, electronics, and steel industries. Its high resistivity and ability to withstand elements without oxidation makes it a popular choice when dealing with large-scale heating elements.

Key reason to select Kanthal over Nicrome due to higher Fusion Temperature (about 300 degrees) which allow us to dry burn without problems and the purity of the metal.

Specifications
22% chromium (Cr), 5.8% aluminum (Al), Iron (Fe) balance
Density: 7.1 g/cubic cm
Tensile strength: 680 n/mm_
Melting Temperature: 1500¡C (2732¡F)
Maximum Operating Temperature: 1400¡C (2550¡F)
Density: 0.256 lbs/cubic in.
Specific heat capacity @ 68¡F: 0.11 Btu/lb¡F

AWG 20: Low Resistance (0.07 ohms/inch)
AWG 22: Low Resistance (0.11 ohms/inch)
AWG 24: Low Resistance (0.175 ohms/inch)
AWG 26: Low Resistance (0.28 ohms/inch)
AWG 28: Low - Standard Resistance (0.44 ohms/inch)
AWG 30: Low - Standard Resistance (0.70 ohms/ inch)
AWG 32: Low - Standard Resistance (1.1 ohms/ inch)
AWG 33: Low - Standard - High Resistance (1.39 ohms/inch)
AWG 34: Standard - High Resistance (1.76 ohms/inch)
