OMNI Board

OMNI Board is the most comprehensive board that is included in Vaporesso premium mods, guaranteeing a consistently reliable performance with a scientific touch. As the foundation of every mod, it is geared towards both new and veteran vapers.

The Omni board will supply you with 6 output modes: Smart VW/CCW/VT(Ni200/SS/Ti)/CCT/
TCR/Bypass. These modes cater for almost any kind of coil that you may be using.

It also features multi protection functions for maximum battery life. The dedicated software would guarantee that your mod stays up-to-date and also can be used to customize the user experience.

OMNI board, as the most advanced personal vaporizer board available, is set to refine your imagination of vaping.

Exploring OMNI Board's Advanced Settings

CCW:

As an advanced setting to VW, CCW stands for Customized Curve of Wattage. You could actually customize the curve of wattage, according to its respective second, up and down in a pattern with this setting. You will be able to select the output for every 1/2 second of the first 5 seconds to minimize ramp up time and maximize pleasure. It is like riding a roller coaster, an excitingly varied series of hits from a vape setting tailored by you that you can have as many times as you wish.

CCT:

As an advanced setting to VT, CCT stands for Customized Curve of Temperature. Have you been upset that the 1st few drags are not hot enough? Have you ever been burnt after vaping for a while? The CCT setting addresses these issues and gives you a truly free vaping experience. With the customized curve of temperature, you could have your 1st few drags at a higher temperature, and then automatically lower it so there's no risk of over-heating after a while. You are the true master of your mod, discovering the fun of vaping.

Smart VW

As an advanced variable output wattage setting mode, the SMART VW will automatically recommend the ideal output power setting for each resistance value when an atomizer is installed, avoiding burning the coil to protect your device and also saving your time and money.

If you still prefer to change the output power, it will again save the changed setting automatically so that when you resume after power off it will start with your preferred setting. It is indeed a smart guard of your mod, always providing you with the ideal output power for your atomizer. Enjoy the SMART VW now.

TCR offers you the option to regulate your device to adapt to any coil type outside the options provided as TC (Ni, SS, Ti) by selecting the respective coefficient of resistance for the metal in use. Feel free to look it up! Here is a quick reference graph

The following shows different TCR value ranges for different coils:

Note:

1. The TCR Value in the sheets is 10x the actual TCR.

2. The total range of TCR values is 1-1000
